Liquid Trap Magnet

Liquid Trap Magnet Specification

Application
Industrial

Material
Stainless Steel 304/316

Composite
No

Surface Finish
Mirror / Matt Finish

Magnet Grade
N35, N52 (for Rare Earth Types)

Product Type
Magnetic Devices

Magnet Category
Permanent Magnets

Magnet Type
Trap magnet

Shape
Cylindrical/Barrel

Size Range
Customized

Weight
Depends on Model and Size

Color
Metallic Silver (Polished Stainless Steel)

Usage & Applications
Food Processing, Pharmaceutical, Chemical Slurry, Dairy, Ceramics, Mining, Paper & Pulp

Capacity
Varies as per Pipeline Diameter

Cleaning Mechanism
Manual or Easy Clean Available

Installation
Inline with Pipeline

Leakage Test
Hydraulically Tested for Leak Proof Performance

End Connection
MS/SS Flange Ends or SMS/TC/Triclover Fittings

Connection Type
Flanged or Threaded

Operating Pressure
Up to 10 Bar (Varies by Design)

Maximum Operating Temperature
Up to 80C (Standard), Higher on Request

No of Magnetic Rods
2 to 8 (Based on Size)

Liquid Trap Magnet Trade Information

Minimum Order Quantity
01 Piece

Payment Terms
Cash in Advance (CID), Cash Advance (CA)

Delivery Time
5-7 Days

Main Export Market(s)
Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Central America, Asia, Africa

Main Domestic Market
All India

About Liquid Trap Magnet

We are a respected manufacturer of Liquid Trap Magnet in the market. It is designed to remove ferrous tramp metal contamination from liquid processing and conveying lines. Single-plate magnet and dual-plate magnet liquid traps effectively remove ferrous particles from fibrous to viscous liquids, as well as from liquids containing larger suspended solids. Liquid Trap Magnet can be availed at reasonable prices.

Advanced Ferrous Separation for Industrial Liquids

Our Liquid Trap Magnet is customised for pipeline use in critical industries like food processing, pharmaceuticals, and chemicals. It is engineered to extract ferrous particles using powerful permanent magnets, while accommodating various connection types and a range of pipeline diameters. Its hygienic stainless steel construction supports both Mirror and Matt finishes, guaranteeing durability and corrosion resistance where it matters most.

Streamlined Maintenance and Reliable Operation

Select from manual or easy-clean mechanisms to suit your cleaning preferences and operational workflow. Each unit is hydraulically tested, ensuring leak-proof performance under pressures up to 10 bar. Choose from a variety of flange and fitting options for seamless integration, while the mirror-polished surface supports quick, residue-free cleaning-vital for sensitive production lines.

FAQ's of Liquid Trap Magnet:

Q: How does the Liquid Trap Magnet work to remove contaminants from liquids?

A: The Liquid Trap Magnet contains multiple magnetic rods arranged inside a cylindrical or barrel-shaped housing. As liquid flows through the trap magnet installed inline with the pipeline, ferrous contaminants are attracted to and held by these rods, ensuring purified product output suitable for stringent industrial applications.

Q: What is the process for cleaning or maintaining the Liquid Trap Magnet?

A: Maintenance can be performed manually or with the easy-clean option, depending on the selected design. To clean, the magnetic rods are withdrawn and contaminants are wiped away. The easy-clean models simplify this by allowing quicker removal of captured particles, which is ideal for reducing downtime in busy processing environments.

Q: Where can this trap magnet be installed in my process line?

A: The Liquid Trap Magnet is designed for inline installation within any liquid-carrying pipeline in industrial settings. Thanks to its customizable connections (MS/SS Flange, SMS, TC, Triclover), it integrates seamlessly into both new and existing pipelines in food, dairy, chemical, and other processing facilities.

Q: What are the benefits of using a hydraulically tested trap magnet?

A: Hydraulic testing ensures the magnet housing is completely leak-proof under operating conditions up to 10 bar, providing operational safety and preventing product loss or contamination. This guarantees reliable, long-term performance in critical processing lines.

Q: When should I consider using higher-grade magnets like N52 for my application?

A: N52 rare earth magnets offer superior magnetic strength compared to standard N35 models. They are recommended when handling fine or weakly magnetic particles, or when maximum contaminant capture efficiency is required-common in pharmaceutical or high-purity processing environments.

Q: What industries commonly use the Liquid Trap Magnet?

A: This product is widely used in food processing, pharmaceutical, dairy, chemical slurry, ceramics, mining, and paper & pulp industries. Its robust design and high separation efficiency make it suitable for processes requiring strict contamination control.

Q: How is the appropriate size and capacity of the Liquid Trap Magnet determined?

A: The size, number of magnetic rods, and overall capacity are customized based on your pipeline's diameter and flow rate requirements. Our team works with you to select the optimal configuration that meets your specific operational needs.
